Tachos und zubehör

Enabels H-D models, equipped with the J1850-bus system, to control instruments and indicator lights. ABE approved. The M-CAN connector connects the Motoscope Speedo and fits straight into the OBD (data link interface/on-board diagnostic port) plug, which is normally used to read-out throuble codes on 04-11 HD-models with 3-pin connector. You will not trigger any trouble codes. Note: Will feed speed, RPM and trouble codes only. Other indicator lights must be taken from the bike's wiring harness. Note: Not compatible with CAN-bus (HD-lan) models.

Fits: > 04-11 H-D  930190

FL speedometer, '62-67 electra face', black/silver. 2:1 MPH

With 5/8-18 threaded speedo cable connector. For your reference only: For identification purposes only we have named the earlier 'FL style' speedo­meter faces with 'model years'. These may not accurately represent actual model years and are for use as reference only. Most FL type speedometers are available with K.M.H. or M.P.H faces. All speedometers from the '36-40' face to the '00-03' face styles feature same dimensions and fit the FL, FLH, Fat Bob, FLST, FXST etc. tank mounted style dash. Note that a small modification to the dash, to fit the re-set knob correctly, may be required. 2:1 ratio is suitable for most front wheel drive, 1:1 drive ratio is suitable for most transmission drive models. 84-95 Softail models may have a different 2.24:1 ratio, of which there are listed a few speedometers. Note: 1991-up turn signals will no longer self cancel. - 60 M.P.H. = 1000 R.P.M. (= 1:1) - 60 M.P.H. = 2000 R.P.M. (= 2:1) - 60 M.P.H. = 2240 R.P.M. (= 2.24:1) - 60 K.M.H. = 700 R.P.M. (= 1:1) - 60 K.M.H. = 1400 R.P.M. (= 2:1)

500204

Active proximity speed sensor for Daytona, Asura and Velona speedometer instruments. Use 1-3 mm sensing distance for a stable function. Place the sensor near the bolt head of the brake rotor, sprocket or something of metal that rotates as the motorcycle is moving. Includes 2 meter long wiring.

Fits:  Fits among others: Asura speedometers: 900384;900385;900386 Velona speedometers: 900403;900493;900494;900387;900893;510143;510152;900387;900893;510154;510156

900404

WHITE ILLUMINATION; ELECTR. DRIVEN; ANALOG 140MPH/KPH FACE; SWITCH BETWEEN MPH/KPH; DOMED PLASTIC SMOKE LENS; STAINLESS HOUSING

 900387

BLACK POWDERCOATED, WITHOUT COVER

Fits: 10-17 XL1200X (SPORTSTER 48)  963065

Functions include Speedometer 0-999 kmh. or mph., trip meter 0-999,99 km or miles, total odometer 0-99.999 km or miles, trip time 0-99:99 hours, tachometer as numbers 0-20.000 rpm, tachometer as lightbar 0-10.000 rpm and shift light 0-20.000 rpm. Includes a Reed wheel sensor with 1.5m cable for the speedometer function in custom applications, although the Motoscope is compatible with, and can be connected to, most stock speedo sensors that might already be in use on the bike. Calibrations are done when it is installed. Small threaded nuts are installed on rear side and mount brackets can be ordered separately. Dimensions: 59mm wide x 21.5mm high x 13mm deep. Weight 32 grams. - Black anodized. Note: With approval. Check your local MCS dealer or the ASC sales department for exact type of approval and validity on bike model and years on the test report.

Fits: Universal

Black or Polished

MOTOGADGET

930171 930173

Polished Or Black

Fits: 84-99(NU) EVO B.T.

930177 930178

Black anodized aluminum, Used to move your OEM speedo to the left side of the cylinder head. All speedo functions are retained Fits: 07-18 XL (excl. XL883C/1200C, XL 1200X/Superlow)   911332

BLACK, WITH 5 INDICATOR LIGHT HOLES  Fits: 04-18 XL (excl. XL883C/1200C, XL 1200/X/Superlow)  519722

Chrome housing & front ring, black face plate. Comes with a LED lighted face, with the possibility to switch the backlight color between white, warm white, yellow, orange, red, green, turquoise, blue and magenta. Great to style match to the bike, other instruments or satisfy your changing taste. This 48mm Ultra-Mini speedometer is electronically driven and has a LCD to display total distance, trip counter (odometer), clock, ambient temperature and more. Available a black or white km/h or mp/h face in a chrome or black housing. Originally designed for use on 94-up H-D models equipped with stock electronic transmission driven speedometers. Can be used in many custom applications since this electronic speedometer can be used with inductive and Hall-effect sensors with npn output but also Reed-sensors and induction sensors (VRS). The speedo can be manually calibrated by entering a known number of sensor pulses or automatically by riding a certain distance. You will need 1 push-button switch (included) to calibrate the speedo and to switch the LCD screen between distance, trip meter and clock. Integrated LED indicator lights include: Red warning light, Blue high beam, Green neutral, Green turn signal. Connectors that fit the rear side of speedo are included as well. Complete with elaborate installation instructions. Note: A universal mounting bracket can be ordered separately, when required, as 941078 (chrome) or 941079 (black). Fits:  Custom applications    583856

CHROME Or Black , FOR 'GENERATION 2' TARGET AND BASIC 48MM SPEEDOS   941078    941079
